22MnB5 Hot Stamping Boron Steel Coil 1.5-3.5mm Pickled Oiled Press Hardening 1500MPa B Pillar

25トン
MOQ
USD 680-860 / Ton
価格
22MnB5 Hot Stamping Boron Steel Coil 1.5-3.5mm Pickled Oiled Press Hardening 1500MPa B Pillar
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
鋼種: 22MnB5(ホウ素マンガン鋼)
標準: EN 10083-3、典型的なホットスタンピング仕様
厚さ: 1.5-3.5mm (狭い公差 +/- 0.08mm)
幅: 600~1600mm、スリット幅300mmから対応可能
コイルID: 508mm/610mm
コイル重量: 5~22トン
配送条件: 熱間圧延、酸洗い、油引き(裸)
炭素含有量: 0.19~0.25%
マンガンの内容: 1.10~1.40%
ほう素の内容: 0.0008~0.0050%
引張強さ(納入時): 450〜700MPa
引張強さ(プレス硬化後): 1500MPa以上
降伏強さ(プレス硬化後): 1050MPa以上
伸び A80(プレス硬化後): 最低5%
エッジ状態: ミルエッジ・スリットエッジ
技術: グレードごとに熱間圧延/冷間圧延
HSコード: 7208250000
ハイライト:

22MnB5 hot stamping boron steel coil

,

Pickled oiled press hardening steel 1500MPa

,

1.5-3.5mm boron steel B pillar coil

基本情報
起源の場所: 中国山東省
ブランド名: Zhengde
証明: ISO 9001:2015, SGS, BV, MTC EN 10204 3.1
モデル番号: ZD-22MnB5-HRPO
お支払配送条件
パッケージの詳細: 防錆紙、プラスチックフィルム、金属エッジプロテクター、木製パレット、スチールストラップを備えた標準的な耐航性のある輸出梱包
受渡し時間: 在庫に7〜15日、生産に20〜30日
支払条件: T/T,L/C 目の前で,ウェスタン・ユニオン
供給の能力: 月80000トン
製品の説明
The 22MnB5 hot stamping boron steel coil is a dedicated press hardening grade produced for lightweight automotive safety structures. Zhengde rolls this boron-manganese steel on automated hot strip mills with strict soaking and coiling temperature control, then pickles and oils the strip so blanks can be cut and formed immediately. After hot stamping and die quenching the material reaches a guaranteed 1500 MPa tensile strength, which lets carmakers replace thick high strength
