Zero Spangle Chromated Galvanized Steel Coil 0.4-1.0mm for Appliance Panels

3メートル トン
MOQ
USD 580-670 / Metric Ton
価格
Zero Spangle Chromated Galvanized Steel Coil 0.4-1.0mm for Appliance Panels
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
コーティングの重量を亜鉛でメッキしなさい: Z60~Z180
鋼種: SGCC / DX51D+Z / DX52D+Z
厚み範囲: 0.4-1.0 mm
幅範囲: 600-1250のmm
表面仕上げ: スパンコールゼロ、スキンパス
表面粗さ: Ra 0.6-1.2μm
油膜: 0.5~1.5g/m2
コイルの内径: 508mm
コイル重量: 3~6MT
ペイントシステム: 粉末塗装 液体塗装
適用グレード: アプライアンスの可視パネル
ハイライト:

Appliance Panel Steel Coil

,

Smooth Surface Galvanized Coil

,

Chromated Appliance Coil

基本情報
起源の場所: 中国
ブランド名: Zhengde
証明: ISO 9001:2015, EN 10204 3.1 Mill Test Certificate
モデル番号: APP-ZS-04
お支払配送条件
パッケージの詳細: 保護フィルム + エッジプロテクター + VCI フィルム、パレット化、家電製品のラインフィードに最適
受渡し時間: 在庫サイズの場合は 10 ~ 20 日、生産には 25 ~ 35 日かかります
支払条件: T/T、L/C アットサイト、ウェスタンユニオン
供給の能力: 1 か月あたり 5000 トン
製品の説明
An appliance panel is judged by its finish, and the finish begins with the coil. This appliance panel galvanized steel coil is zero spangle and skin passed, 0.4 mm to 1.0 mm thick, chromated and lightly oiled, with a surface roughness window chosen so that powder coating and liquid paint flow out to an even film without orange peel. The substrate is a low carbon draw quality steel with controlled silicon and phosphorus, which keeps the panel flat after blanking and prevents
